What is SHSL?
So High So Low high pass/low pass filter and preamp based on Korg MS-20 filter and Moogerfooger preamp.
Where can I find demos?
There are demos on YouTube, on our web site and Instagram.
Are the filters in series or parallel?
The filters are arranged in series.
Does the SHSL make a bandpass filter?
Yes, the high pass and low pass filters are arranged in series, so you can use them as a bandpass.
Is SHSL CV controllable?
Yes, you can connect CV to both: high pass and low pass filters.
What about the EXP inputs?
You can connect your expression pedal to either high pass or low pass input and control the cutoff with it (similar to a wah pedal for example).
Does SHSL work with bass?
Absolutely! SHSL loves bass an it is a terrific combo.
What is the most important thing I should take care of?
Not to run the So High So Low pedal on anything higher than 9V. Otherwise you'll fry the pedal.
What power supply is required?
Only 9V center negative (Boss type) power supply is supported. There is a voltage conversion inside the pedal and it will fry if you connect a higher voltage. The minimum current must be 200mA (though 300mA is recommended for proper operation)
What is the required current draw?
SHSL needs current of minimum of 200mA, though we recommend 300mA minimum for stable operation.
Do the SHSL filters oscillate?
Yes, both filters can oscillate when the resonance is past the oscillation (OSC) point.
Is SHSL a true bypass pedal?
Yes, So High So Low is a true bypass.
Does SHSL need some fancy power adaptor?
No, we have taken care that SHSL runs on a standard 9V Boss type power supply. We are boosting the voltage internally for the proper operation of the filters and preamp.
Does SHSL have stereo in/out?
SHSL Mk.II is a mono pedal.
Is the preamp located before or after the filters?
The preamp is located before the filters.
Does SHSL have expression/midi/CV connectivity?
SHSL has expression controls for each filter cutoff and two CV inputs: one for high pass, one for low pass.
Do you ship internationally?
Yes, we are shipping worldwide.
Moreover, SHSL will be available with the UK and USA dealers.
